Your Professional Pure Titanium Sheets Supplier
Ruihang, as a direct factory of titanium products production, is specilized in R&D,production. The company is located in " China's Titanium Valley" , boosting the titanium industry in the world. The company mainly produces Titanium and Titanium Alloy products with the whole industry chain,including smelting,forging, straightening,rolling,surface treating,testing process.We are a technology and innovation enterprise whom collecting R&D, production and sales as one unit. Shaanxi Ruihang Elaborate Materials I/E Co.,Ltd is a holding subsidiary of the Group also,whom is in charge of import and export business of the Group.
Pure titanium sheets are flat, thin sheets of commercially pure titanium (often over 99.5% titanium) known for their high strength-to-weight ratio, excellent corrosion resistance, and biocompatibility. Due to these properties, they are used in demanding applications like aerospace, marine, medical implants, and chemical processing. The softness and formability of pure titanium sheets vary depending on the specific grade, with Grade 1 being the most ductile and Grade 4 being the strongest.
Specifications
|
Metric |
English |
Remarks |
|
|
Physical Properties |
|||
|
Density |
4.51g/cc |
0.163 lb/in³ |
|
|
Mechanical Properties |
|||
|
Hardness, Rockwell B |
98 |
98 |
|
|
Shear Modulus |
38 MPa |
5510 ksi |
|
|
Shear Strength |
380 MPa |
55100 psi |
|
|
Tensile Strength, Ultimate |
430 MPa |
62400 psi |
|
|
Tensile Strength, Yield |
340 MPa |
49300 psi |
|
|
Elongation at Break |
28% |
28% |
|
|
Charpy Impact |
65 J |
47.9 ft-lb |
V-notch |
Key characteristics
Strength-to-weight ratio: Pure titanium sheets are stronger than steel by weight and significantly lighter than steel, making them ideal for applications where both strength and low weight are critical.
Corrosion resistance: They form a protective oxide layer that provides excellent resistance to corrosion in a wide range of environments, including saltwater and aggressive chemicals.
Biocompatibility: Pure titanium is non-toxic and non-reactive, making it safe for use in the human body, which is why it is used for surgical implants and dental devices.
Formability: The ease with which pure titanium can be formed into different shapes varies by grade. Grade 1 is the softest and most easily formed, while higher grades have increased strength but reduced ductility.
The properties of pure titanium are:
Exceptional corrosion resistance especially in saltwater environments
1
>>
Lower tensile strength compared to alloys (275-550 MPa)
2
>>
Better formability and weldability
3
>>
Biocompatibility for medical applications
4
>>
Density of around 4.5 g/cm³, about 60% of steel
5
Rolling Processing of Grade 3 Pure Titanium Plate
(1)Hot Rolled Processing:
Hot rolling is carried out above the recrystallization temperature of titanium alloys and is suitable for the production of medium-thickness plates (such as those with a thickness of more than 5mm). Hot rolling can enable titanium alloy plates to obtain good internal structure and mechanical properties, and improve the plasticity and toughness of the plates.
(2)Cold Rolled Processing:
Cold rolling is a rolling process carried out at room temperature, and is mainly used for the production of thin plates (such as those with a thickness ranging from 0.3 to 5mm), which can achieve higher surface accuracy and dimensional accuracy. The surface of the cold-rolled titanium alloy sheet is smooth and the thickness is uniform, making it suitable for components with high requirements for the surface quality of the sheet.
(3)Comparison of Rolling Processes:
Hot rolling and cold rolling both have their own advantages and disadvantages.
Hot rolling has a high production efficiency, but its surface quality is relatively poor.
Cold-rolled surfaces have good quality, but the production cost is relatively high.
In actual production, the appropriate rolling process can be selected according to the product requirements.
Applications
Aerospace: Used in airframe components, engine parts, and other lightweight, corrosion-resistant structures.
Marine: Ideal for desalination plants, shipbuilding, and other applications exposed to seawater.
Chemical Processing: Used in heat exchangers, reactor vessels, piping systems, and other equipment that faces corrosive chemicals.
Medical: Commonly used in medical implants, surgical instruments, and devices due to its biocompatibility and corrosion resistance.
Architecture: Employed in architectural applications for its modern look and corrosion resistance in exterior structures.
Power Generation: Used in components exposed to seawater in cooling systems, particularly in power plants or offshore facilities.
Packaging & Shipping
Package Terms:Moisture-proof cloth, foam cotton inside, wooden case outside.
Shipping Terms:Express,Air,Shipping or as your choice.
Authorized Certificate
FAQ
As one of the leading pure titanium sheets manufacturers and suppliers in China, we warmly welcome you to buy high-grade pure titanium sheets for sale here and get quotation from our factory. For price consultation, contact us.
Gr2 Titanium Sheet, Gr3 Titanium Sheet, Gr4 Titanium Sheet
