Gr5 Ti 6AI 4V Titanium Wire
Gr5 Ti 6AI 4V Titanium Wire suppliers
Gr5 Ti 6AI 4V Titanium Wire factory

Gr5 Ti 6AI 4V Titanium Wire

Name: China Gr5 Ti 6AI 4V Titanium Wire Manufacturers Suppliers - Factory Direct Price - Ruihang Elaborate Materials
Brand: Ruihang
SKU: 286757580

Name: Gr5 Titanium Wire
Grade: Grade5
Standard: ASTM B863/AMS 4928
Machining Technology: Hot Rolling or Cold Drawing
Condition: Annealed
Surface Treatment: Pickled or Polished

Send Inquiry

Description

Technical Parameters

Products Description

Gr5 titanium wire is a circular material with diameter < 6 mm, manufactured from Ti6 Al 4V alloy in compliance with ASTM B863 or AMS 4928 standard.

Grade 5 titanium wire is the most widely used alpha-beta titanium alloy wire, defined by the composition Ti-6Al-4V (~6% aluminum, ~4% vanadium, balance titanium). It balances high strength, low density, excellent corrosion resistance, and biocompatibility, making it a staple for aerospace, medical, additive manufacturing (3D printing), and marine/chemical applications.

Chemical Composition (wt%)

Element	Al	V	Fe	O	C	N	H	Res. (each)	Res. (total)	Ti
Min (wt%)	5.50	3.50	-	-	-	-	-	-	-	Balance
Max (wt%)	6.75	4.50	0.40	0.20	0.08	0.05	0.015	0.10	0.40	Balance

Mechanical Properties

Item	Value
Ultimate Tensile Strength (UTS)	≥ 860 MPa
Yield Strength (0.2% offset)	≥ 795 MPa
Elongation (L=4D)	≥ 10%
Reduction of Area	≥ 25%
Modulus of Elasticity	~110 GPa
Poisson's Ratio	~0.31
Hardness (HV)	~310 – 350 HV

Physical Properties

Property	Value
Density	4.43 g/cm³
Melting Range	1604 ~ 1660 °C
Specific Heat Capacity (25°C)	526 J/(kg·K)
Thermal Conductivity (25°C)	6.7 W/(m·K)
Coefficient of Linear Thermal Expansion (20–100°C)	8.6 ×10⁻⁶ /°C
Electrical Resistivity	170 μΩ·cm
Elastic Modulus	110 GPa
Poisson's Ratio	0.31
Magnetic Property	Non-magnetic

Specification

Wire Type	Diameter Range	Form	Specification
Fine wire	0.3–1.0 mm	Coils	Weight: several kg to 20 kg
Medium wire	1.2–3.0 mm	Coils	Weight: several kg to 20 kg
Thick wire	4.0–6.0 mm	Bars	Length: 1000/2000/3000/4000/5000 mm (customizable per client request)

Company Advantages

Capability of Titanium Wires Production

Monthly output of titanium wire: 50 metric tons

250mt rolling mill × 1 set

40mt drawing machine × 1 set

20mt drawing machine × 1 set

Electric resistance furnace × 1 set

Annealing furnace × 1 set

Skew roll straightening machine × 1 set

Company advantages

1.Sufficient production facilities ensure prompt processing of customer orders.
2.Certifications
Obtained EN ISO 9001:2015 and EN 9100:2018 certifications
Certified by Bureau Veritas (BV) France
Certification scope: Europe aerospace products
Certification year: 2025
3.Testing Facility
Own a dedicated testing center
Equipped with over 10 advanced testing instruments
4.Competitive Advantages
Leverage superior local industrial cluster
High production efficiency and high yield rate
Deliver competitive product prices
Provide reliable after-sales service

Packing and Shipment

1. Payment Terms

T/T: 30% deposit upon order confirmation; balance 70% before shipment / before B/L release.
L/C: Irrevocable sight L/C acceptable for bulk orders.
Others: Credit Card,Paypal,Western Union,Moneygram,etc

2. Shipment

Lead time: to be confirmed according to the order.
Transport:

Small quantity: Express (CR express/DHL / FedEx / UPS / TNT)

Bulk: By sea / by air

3. Packing

Inner: Anti-rust paper + vacuum packaging + foam protection.
Outer: Plywood / wooden case.
Markings: Product grade, quantity, gross weight, net weight, country of origin, "Fragile", "Handle with care", "Keep dry".

Suitable for long-distance ocean / air transportation, shockproof, moistureproof, anti-corrosion.

FAQ

Q: Can Gr5 titanium wire be welded?

A: Yes. It is commonly used as welding wire (ERTi‑5). Welding requires high‑purity argon shielding to prevent oxidation and hydrogen embrittlement.

Q: Are you a direct manufacturer or trading company?

A: We're a manufacturer with more than 18 years of professional production experience.

Q: What are the packaging and storage requirements?

A: Packed in vacuum‑sealed bags or moisture‑proof drums.

Store in dry, ventilated areas to avoid oxidation and corrosion.

Q: What are the typical applications?

Aerospace: Aircraft fasteners, engine components, structural parts.

Medical: Surgical implants, orthopedic devices, dental fixtures.

Marine: Seawater equipment, offshore structures.

Industrial: Chemical reactors, heat exchangers, springs.

3D printing: Additive manufacturing feedstock.+

Contact us

Ruihang Group specialized in manufacturing of Titanium & Titanium Alloy Plate/Sheet, Bar, Pipe, Ring, Forging Stock & Section. The quality apply with the standard of AMS, ASTM, MIL, ISO, GB, GJB.

We are a technology and innovation enterprise that integrates R&D, production and sales into one integrated system. For any purchasing needs, feel free to contact us at email.
